• Page 1 12V GMC Sierra Denali Owner’s Manual and Assembly Instructions (2-Person Assembly Recommended) Model #: W461-G, W461-G-F Read and understand the entire manual before assembly and operation. The vehicle must be assembled by an adult who has read and understands the instructions.

• Page 2: Specifications

  Introduction Thank you for purchasing this vehicle from RollPlay. We hope the rider enjoys it for miles to come. Please read this instruction guide carefully before assembling and operating the vehicle. Please have your model number and serial number ready before calling. Please have proof of purchase.
• Page 3 Contact Customer Service if you need assistance or replacement parts. Please have your model number and serial number ready before calling. Please have proof of purchase. Keep your sales receipt or register your product at www.rollplay.net as we may require proof of purchase. customerservice@rollplay.net 1-888-982-9309...

• Page 4: Table Of Contents

  Table of Contents Safety ............5 Parts ............7 Charging Instructions .......8 Assemble the Rear Support Bars ....9 Install the Rear Support Bars ....10 Install the Rear Wheel Axle .....11 Install the Gear Boxes ......12 Assemble the Rear Wheels .....13 Assemble the Front Wheels ....14 Attach the Truck Bed ......15 Attach the Mirrors ........16 Attach the Windshield and Dashboard ..17...

• Page 5: Safety

  Safety WARNING: SAFETY RIDING RULES PREVENT INJURIES AND DEATHS: NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view when child is in vehicle. Direct adult supervision is REQUIRED. NEVER use on roadways, near cars, on or near steep inclines or steps, swimming pools or other bodies of water.
• Page 6 Safety (Continued) WARNING: BATTERY SAFETY • Battery posts, terminals and related accessories contain lead and lead compound (asic) chemicals known to the state of California to cause cancer, reproductive harm, and are toxic and corrosive. DO NOT open the battery. •...

• Page 7: Parts

  Parts Not Included: 1. Gear Boxes 11. Rear Axle 2. 12V Battery 12. Battery Charger 3. Right Mirror 13. Wheel Covers (4) 4. Left Mirror 14. Front Wheels (2) • Phillips screwdriver • 2 AA batteries 5. Right Door 15. Rear Wheels (2) 6.

• Page 8: Charging Instructions

  Charging Instructions YOU MUST CHARGE THE BATTERY FOR 24 HOURS BEFORE THE FIRST USE! ONLY AN ADULT SHOULD HANDLE THE BATTERY AND CHARGER. Connect the Battery: 1. Ensure the vehicle is stopped and turned off. 2. Unlock and remove the seat. 3.

• Page 9: Assemble The Rear Support Bars

  Assemble the Rear Support Bars 2-Person Assembly Recommended 1. Locate the right (8) and left (9) support bars and the rear support lateral bar (10). 2. Insert the rear support lateral bar into the square slots on the rear support side bars.

• Page 10: Install The Rear Support Bars

  Install the Rear Support Bars 1. Carefully flip the truck body on its back for easier assembly (use a soft surface to avoid any scratches or damage). 2. Slide the assembled rear support bars into the square holes on the back of the truck body.

• Page 11: Install The Rear Wheel Axle

  Install the Rear Wheel Axle 1. Locate the rear wheel axle (11). Remove the protective sleeve from the axle. 2. Remove the lock nut and washer from both sides of the rear axle. Note: if unable to locate lock nut and washer, they may be stuck in the protective sleeve. 3.

• Page 12: Install The Gear Boxes

  Install the Gear Boxes 1. With the truck body still on its back, locate the two holes on either side of the truck body with the white gearbox connector and yellow gearbox connector. 2. Insert the gearbox wire into the hole on the truck body. Slide the left gear box (1) onto the rear axle with the white gears facing out until it sits completely in the gear box bracket and the silver cylindrical end fits completely into the hole that leads to the battery compartment.

• Page 13: Assemble The Rear Wheels

  Assemble the Rear Wheels Helpful Tip: If you encounter trouble fitting both wheels onto the rear axle, then your rear wheel axle may need to be realigned. Remove both wheels from the rear wheel axle. Using two hands, push down on the rear wheel axle and slide it gently toward the side of the vehicle that needs more room.

• Page 14: Assemble The Front Wheels

  Assemble the Front Wheels 1. Remove the protective sleeve, lock nut, and washers from the front axle. 2. Slide a thick washer onto the front axle. Note: if unable to locate lock nut and washer, they may be stuck in the protective sleeve. 3.

• Page 15: Attach The Truck Bed

  Attach the Truck Bed gearbox connector Helpful Tip: Ensure the white battery connector is connected to the white engine connector. Ensure the white gear box connector is connected to the white engine connector. Ensure the yellow gear box connector is connected to the yellow engine connector.

• Page 16: Attach The Mirrors

  Attach the Mirrors 1. Remove the mirrors (3 and 4) from the plastic bags. 2. Align the hole on the mirror with the hole on the truck. 3. Insert the screw into the hole and fasten the nut with a screwdriver to secure the mirror.

• Page 17: Attach The Windshield And Dashboard

  Attach the Windshield and Dashboard 1. Attach the wire connector coming from the dashboard (16) body (located in the dashboard) to the wire connector attached to the truck body. 2. Match the plastic inserts on the dashboard with the four slots on the truck body and insert into the truck body at a 45 degree angle.

• Page 18: Attach The Steering Rod

  Attach the Steering Rod 1. Carefully flip the truck body on its back for easier assembly (use a soft surface to avoid any scratches or damage). 2. Locate the steering rod (25). 3. Insert the straight end of the steering rod into the steering rod hole on the underside of the dashboard.

• Page 19: Assemble The Steering Wheel

  Assemble the Steering Wheel Helpful Tip: DO NOT mix old and new batteries Have one person hold the steering DO NOT mix alkaline, standard (carbon-zinc) or rod in place to prevent it from sliding down while the other person rechargeable (nickel-cadmium) batteries. attaches the steering wheel 1.

• Page 20: Attach The Doors

  Attach the Doors Truck frame post 1. Align the doors with the interior facing the inside of the truck. 2. Position the hole on the door over the hole on the truck body and slide the post on the bottom of the door into the hole on the truck body side. 3.

• Page 21: Attach The Tailgate / Wheel Covers

  Attach the Tailgate / Wheel Covers 1. Keeping the tailgate horizontal, align the tailgate with the holes on the truck bed. 2. Once the tailgate is completely aligned with the slots on the bed, lift the bed door up until it clicks into place. 3.

• Page 22: Battery Attachment

  Battery Attachment 1. Attach the battery connector to the engine connector. Place the connectors and wires in the battery compartment. 2. Important! Before using the truck for the first time, the battery needs to be charged for a full 24 hours.

• Page 23: Attach The Seat

  Attach the Seat 1. Align the seat over the battery compartment. 2. Ensure the locking mechanism aligns with the holes. 3. Slide the hooks onto the back of the seat into the slots on the truck body. 4. Turn the thumbscrew clockwise until it faces the lock position to properly secure in place.

• Page 24: Operation Instructions

  Operation Instructions Screw 1. Press the left and right steering wheel buttons for horn (a) and engine sounds (b). 2. Turn the power switch to turn on the truck. Turn the power switch again to turn off the truck. 3. Volume Control: Turn right to turn on the MP3 player. Adjusts the volume on the MP3 player.

• Page 25: Maintenance

  Maintenance Important Battery and Charger Information • Only an adult who has read and understands the safety warnings may handle and operate the battery and battery charger. Keep away from children. • Charge the battery for 24 hours before using the vehicle for the first time.

• Page 26: General Care

  General Care • Regularly inspect all vehicle parts to ensure they are in good working condition. • Regularly inspect the charger, cord, plug, and other related parts for damage. • Remove any damaged parts and immediately contact Customer Service for replacement parts. See Service and Repairs on Page 30 for more information.

• Page 27: Troubleshooting Guide

  Troubleshooting Guide Completely read through the manual and troubleshooting guide before contacting Customer Service. Problem Potential Cause Solution Vehicle does not run Battery is low Recharge the battery Thermal fuse tripped This product uses a recoverable fuse which will automatically cut power to the truck if the current is overflowed.
• Page 28 Problem Potential Cause Solution Vehicle needs a push to Loose wires or loose Ensure the battery connectors start connectors are securely attached. If wires are loose, contact Customer Service for repairs “Dead spot” on motor A “dead spot” means electricity is not being delivered to the terminal.

• Page 29: Service And Repairs

  Hours: 9 AM - 5 PM (CST), Monday - Friday 888-982-9309 Phone: 1- Email: customerservice@rollplay.net Web: www.rollplay.net For a list of available replacement parts, please visit www.rollplay.net. WE WILL REQUIRE PROOF OF PURCHASE. Please save your sales receipt or register your product at www.rollplay.net...

• Page 30: Warranty

  This warranty does not cover, and is not intended to exclude any liability on the part of RollPlay, whether under this warranty or implied by law for any indirect or consequential damages for breach of warranty. Some states may not allow the exclusion or limitation so this limitation may not apply to you.

• Page 31: Product Registration

  City: State: Zip Code: Email: Phone: Date of Purchase: The following product information is on the cover of the owner’s manual. Product Name: Model Number: Serial Number: Retailer Place of Purchase: Questions or comments? Contact us at www.rollplay.net or 1-888-982-9309...
